Our Most Popular Blower setup " 10.2" TALL DECK BB Chevy All Fuels ok
2222 TBS Billet 8 -71 6 point stripping For Any fuel - High Helix Rotors.
Includes 2 V Belt accessory & complete 8mm polished drive system
18 Point Stripping option for more boost
We sometimes use 2222- 2220 Billet Blowers same price same look.
Has 300 rotors which can be used with any fuel, but for methanol only,
we use a 200 rotor 2222-200 , or 18 point optional stripping
Blower Shop 8-71 Complete Big Block 2V belt Standard Deck Chevy Special
Includes:
2222 Billet 8 -71 Stripped for Gas, or E-85 , 6 point stripped
High Helix Billet Rotors- w Sight glass and pressure relief valve
Polished Blower Shop Rec port intake manifold w pop off valve -
Gaskets-Studs kit-
Uses your balancer- OR You can get a Hub or Innovators West Harmonic Balancer from us -
Be sure we know if it is internal or external balanced
2V Belt accessory pulley - OR your choice or choose Serpentine if you like
8mm Polished Drive system - any ratio we decide on from 20% under to 25% over
( custom for your engine )
Blower Shop Snout assembly- Snout mounted idler assembly
Polished carb. Top for 1x 4150 or 2 x 4150or no tp if you choose an injection hat
Ready to Install
should make about 13 lbs boost on a 502 cu in at 10% overdrive
15 lbs at 20% overdrive
We stock Innovators West Harmonic Balancers and RCD Blower Hubs
You can choose to run without a balancer since the blower belt absorbs the harmonic vibrations.
Some engine Builders however insist on a Balancer, so we like to do what they want.
Balancers begin at $450 and go up depending on keyway, and if you need crank trigger magnets
. Hubs are around $220 and up - they are all double keyway.
