THE BLOWER SHOP TBS-2339 10-71 EFI FRONT OFFSET INJECTOR Blower SETUP / Hi-Helix BILLET ROTORS (18PT.) Front Offset
Thumbnail Filmstrip of TBS-2339 10-71 EFI FRONT OFFSET INJECTOR Blower SETUP / Hi-Helix BILLET ROTORS (18PT.) FO Images
Complete Setup for BB chevy Std Deck w Tall Deck Option
10-71 FRONT OFFSET EFI INJECTOR BILLET CASE / HIGH-HELIX BILLET ROTORS (18PT.) FRONT OFFSET #2339 ( Clears the distributor on a BB Chevy
4 injector Fuel Rail on each side - holds 8 EFI injectors EV-1
4 injector Fuel Rail on each side - holds 8 EFI injectors EV-1
Includes:
Drive Kit - Polished w Manifold-Pulleys 8mm-Idler- Throttle Body Adapter- Belt-accessory Pulleys
Will deliver on a BB up to 600 inches -and puts the Injectors in the Blower Case
This is the first ever supercharger that we've tailored directly for EFI.
This is the first ever supercharger that we've tailored directly for EFI.
Traditionally, you would run EFI with an injector plate on top of the supercharger.
Where this works, we have found increased performance by bringing the fuel injectors down into the side of the blower case.
Air flows better and easier when it is dry.
By injecting fuel mid way in the case, it allows dry air to more efficiently fill the rotor cavity at a higher velocity.
This increase in air velocity equates to more volume, which ultimately means more boost.
We are also taking advantage of the cooling effects of the fuel.
The blower needs the fuel to help cool and lubricate the rotors.
This new location injects the fuel right where the blower is starting to heat the air.
After being subjected to Drag Week in 2019, we have seen that this increased volume with a cooler air charge is a
near perfect situation in the blower world resulting in a more efficient supercharger.
