SKU: TBS-2005-Black-Non-Stripped
TBS-2005 6V-71 NON STRIPPED Black Blower TBS Billet Polished Blower Cast Rotors

2005   6V-71  NON TEFLON Stripped Black Blower  ( Blower Only )

Case is 1" Shorter than a  6-71

6-71 Front - New Billet Case-   Short Rotors for  good boost control for street engines , Marine, Small engine Bracket Cars- Street Rods   -

Gas-E-85 - Methanol   CAST 3 Lobe 60 degree rotors NOT hard anodized.

Call Braden  at 615-457-3192

6V-71 Billet Case / Cast 3 Lobe Rotors Specs:

CNC machined 6061-T6 Aluminum

Description

The 6V-71 Blower   Reasonable alternative to the 250 mini blower

The 6V-71 blower is molded for stop light to stop light, tire-smokin' boost. The 6V displaces 327 cubic inches of air per revolution. It showcases great throttle response due to its , large diameter 3 lobe rotors. This allows for a slightly higher rotor speed, which gives a better signal to the carburetors. The recessed bearing plates are based on a similar design as our race blower, which allows for a cooler inlet charge and reduces the horsepower necessary to turn the supercharger.

The 6V offers a more affordable option for most street and mild marine applications. It has become an increased popularity for street applications due to its size. The 6V-71 case uses the same inlet and outlet, and bolt pattern as the 6-71, and fits the standard 6-71 manifold.

The 6 V  is in reference to the Detroit Diesel Blower which came on the v series engine as opposed to the 6-71 on the inline. We only use the rotors and gears and put them in a 6-71 style case to be used for aftermarket Hot Rod Supercharger intake manifolds.

This is a good substitute for the  250 mini Blower which are hard to come by .  It can easily add .3 tenths to a Bracket car   just adding this blower with Teflon strips

(2005) 6V-71 Billet Case / Cast 3 Lobe Rotors (327 CID)  8-1/2"  Tall

Can make up to 18 lbs on a 400 cu in engine -  at 30% over

Runs cool on gas  on street engines.
