COMPARE
FEATURES |
PCT 0 |
PCT 1
PLUS |
PCT 1
Z-PLUS |
PCT 3
PLUS |
PCT3
Z-PLUS |
|
Pro-Dial
Dial Board Outputs |
X |
✔ |
✔ |
✔ |
✔ |
|
NEW!
Z-Force Mode |
X |
X |
✔ |
X |
✔ |
|
Standard
Mode |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Cross-Over
Delay |
✔ |
✔ |
✔ |
✔ |
✔ |
|
2-Hit
Interface |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Transbrake
Lockout |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Bump-Down |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Bump-Up |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Flinch
Protection |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Full
Tree / Pro Tree |
X |
✔ |
✔ |
✔ |
✔ |
|
Timer #
1 |
X |
✔ |
✔ |
✔ |
✔ |
|
Timer #
2 |
X |
X |
X |
✔ |
✔ |
|
Timer #
3 |
X |
X |
X |
✔ |
✔ |
|
Timer
"Bump" |
X |
✔ |
✔ |
✔ |
✔ |
|
Pro-Stage
Starting Line Control |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Line-Lock
Output |
✔ |
✔ |
✔ |
✔ |
✔ |
SMALL IN SIZE � HUGE IN
FEATURES
- NEW!
PRO-DIAL DIAL BOARD OUTPUTS-- (2) Fiber optic outputs capable of of
controlling TWO Pro-Dial dial boards. Automatically sends your dial-in to
any of our Pro-Dial dial boards. No need for a separate controller
anymore! (DIAL BOARD(S) AVAILABLE SEPARATELY)
- AUTOMATIC
CROSSOVER / CROSSTALK-enter dial-ins, react to the first
"flash" and let the box do the math.
- SMALL
SIZE- 4.5"W x 3.5"H x 2.75"Deep---allows unit to fit
virtually anywhere (leaving room for a tachometer and other gauges).
- BUMP
DOWN- correct for late reactions (adjustable to the .001sec.
increments)
- NEW!
�BUMP UP� �separate
button allows you the opportunity to �Bump
Up� (adjustable to the .001sec.
increments) without losing the chance to �Bump
Down�.
- DOUBLE-HIT-take
two "shots" at the tree and leave on your quickest reaction.
- LARGE
LCD DISPLAY- new blue backlighting for easy day/night viewing.
- QUICK
SET SWITCHES-allows nearly instant changes to any setting (no more
panic trying to make last second changes).
- RUN
INFO- automatically displays reaction differential and �Bump� counts .
- TRANSBRAKE
LOCKOUT- prevents accidental transbrake lockup (adjustable timer).
- FLINCH
PROTECTION- save yourself from known red lights
- RESET
SWITCH- instantly allows you to stop the delay box cycle, and be race
ready
- LINELOCK-
versatile output for connecting linelock, "launch-control"
throttle stop, etc.
- PRO-STAGE-
patented system developed by Frank Hawley, allows you to stage at an idle
for both Full tree and Pro tree for improved concentration and
consistency. Goes to full throttle when transbrake is activated on Pro
tree, and waits until your tree starts on a Full tree.
- FULL
TREE / PRO TREE- allows you to enter two totally different run
programs .
- TIMERS-
Three (3) separate timers to control t-stop, shifter, nitrous, etc. during
the run.
- LED
INDICATORS- status lights show when each output is activated.
- OVERLOAD
PROTECTION- self protection from overloads and shorts on all outputs.
- WARRANTY-
So confident in our products, we offer an unprecedented 2-year warranty!
- DASH
INSTALLATION- add that �Professional� look by recess mounting with our new terminated Dash Kit,
available separately.
