SKU: JB-001
Joe-Blo JB-001 EFI Blower Injector Plate Bird-Bug-Shotgun- - Hidden Injector Plate EFI Injectors

JB-001            This plate is designed to accept the LS3 style injectors - 1.48" (37.592mm) from O-ring to o-ring.  ( USE JB-005 for BAU injectors )

EFI for Hat Injectors on a Blower- Birdcatcher - Bugcatcher -  Totally Hidden

Fuel goes in one side and out the other  - Not a Deadhead system-

Quality made-   in AU

Allows you to run UP TO 8 Injectors  inline.

8- 60 lb will support  600 hp

8-  85 lb will support 800 hp

8- 95 lb will support 1000-1100   hp* This plate can be  restrictive for over 1100  hp  see our 4336  plate  for over 1100 hp

Hides the injectors under the Hat

Polished 1" Thick edge

Our new JB-001 deign is finished.

It has been developed to increase clearance with the wire plugs and also help increase airflow into the blower.

By putting all the injectors in a straight line all this has been achieved.

Also there is a radius on the leading edges for better flow.

The fuel rail is now anodised to stop corrosion from E-85 or alky fuels and it has a larger bore size of 1".

Its also made from one piece billet aluminium which eliminates the adaptor and 4 o-rings which are potential leak points.

The rear block section has also received some better porting for better fuel flow.

Fuel enters and returns from the rear

Comes with  gaskets

INJECTORS NOT INCLUDED

This plate is designed to accept the LS3 style injectors - 1.48" (37.592mm) from o-ring to o-ring.
