Purchase IW-846 Innovators West LS BLOWER PATTERN - Corvette Spacing No Serpentines

SKU: IW-846
IW-846 Innovators West LS BLOWER PATTERN - Corvette Spacing No Serpentines

Name: IW-846 Innovators West LS BLOWER PATTERN - Corvette Spacing No Serpentines
Brand: Alkydigger Fuel Injection-Superchargers-Ignitions
SKU: IW-846
Price: 555 USD
Availability: InStock

$555.00

-2 available for immediate delivery

Crank Trigger Magnets:

Keyway:

Crank Trigger Bracket: No Crank Trigger Bracket 1037 LSX Chevy Drivers Side Crank Trigger Bracket + $170.00 1038 LSX Chevy Passenger Side Crank Trigger Bracket + $170.00

966 - Crankshaft Pin Kit for Corvette LS1/2/3/6 Engines (not LS7) +$90.00

Crank Trigger Sensor +$90.00

1/4 " AND 3/16" BOTH +$30.00

Qty

IW- 846 LS Chevy Balancer- for BLOWERS Has 6 bolt Blower BOLT pattern NO 6 RIB serpentine

Recommended - With dual 3/16" keyways can use pin kit instead

Just because you're running a Roots Style Blower doesn't mean you have to run a solid hub, you can STILL run a Damper and SAVE YOUR CRANK!

This 7" Diameter SFI 18.1 rated Racing Balancer is designed for Roots Blower Pulleys to bolt right up using the 2.760" bolt pattern and 2" male pulley register. It's fully engraved for setting timing and is also available with integrated flying magnet crank trigger system.

The damper comes standard with Corvette length hub.

NOTE: Innovators West specific pin kit required when used with a stock non-keyed crankshaft.

Crankshaft Pin Kit - LS1/LS2 Corvette #966

Crankshaft Pin Kit for Corvette LS1/2/3/6 Engines (not LS7).

Designed for use with Innovators West dampers. Will not work with OEM or other aftermarket dampers.

Options

Flying Magnet Crank Trigger Option

Get rid of your separate Crank Trigger Wheel by integrating it into the Damper itself! - Saves on average about 9 Ounces over the MSD Crank Trigger Wheel.
LS Corvette Crank Pin Kit #966 Crankshaft Pin Kit for Corvette LS1/2/3/6 Engines. Will not work with LS7 engine.
Designed for use with Innovators West dampers. For Stock Crankshafts Only.
Crank Trigger Sensor Option

3/4-16 UNF Flying Magnet Crank Trigger Sensor - Direct Replacement for MSD #8276. Designed to
work with Integrated IW Flying Magnet Balancer Option and Brackets.
Crank Trigger Bracket Option

Bolt on a matching billet aluminum sensor bracket and mounting hardware, with either passenger (std) or drivers side mounting options.
Dual Keyway Option

The double keyway option requires that the factory or aftermarket crankshaft be removed from the engine and a second keyway
cut into the snout of the crankshaft. DO NOT run a double keyed damper on a crankshaft without the double keys. Failure to the damper
hub can happen without the supporting key in the broached keyway slot. The dual keyway option is for Supercharged or
Extreme Duty Applications (typically over 750 rwhp). Without the double key modification your crankshaft in these
high horsepower applications can lead to the failure of the damper hub and/or the single keyway which results in damage to the damper and the crankshaft snout.

Details

Diameter: 7.00"
Weight: 8.2lbs
6 Bolt, 2.760" Pulley Pattern.
Male 2 Pulley Register for TBS and other Roots Style Blower Pulleys.
Exceeds SFI 18.1 standards and is marked on front with SFI Sticker, and on the rear with SFI number stamped into unit.
LS Blower , LS 6 Bolt , LS Blower Balancer .
