SKU: IW-10200
10200 Tool - Innovators West Harmonic Balancer Puller/Installer

Name: 10200 Tool - Harmonic Balancer Puller/Installer kit With Options
Brand: Alkydigger Fuel Injection-Superchargers-Ignitions
SKU: IW-10200
Price: 145 USD
Availability: InStock

$145.00

Adapter: GM and LS Crankshafts 1/2"-20 to M16-2.0 X 4.75" + $40.00 Adapter for Ford GT500 Crankshafts 1/2"-20 to M12-1.5 X 3.5" + $40.00 Adapter for Ford Mod Motor Crankshafts 1/2"-20 to M12-1.5 X 1.5" + $40.00

Qty

Description

Special Order - No Returns

Made in Tiawan

This kit features an exclusive Needle Roller Thrust Bearing which is utilized during both pushing and pulling operations providing minimal friction.

This unique feature ensures proper balancer alignment with the crank centerline and provides smooth, consistent pressure and seating any time, every time.

This Kit can also be used for steering wheels, pulleys and other similar items.

Options

#10201 - Adapter for GM LS Crankshafts

1/2"-20 to M16-2.0 X 4.75"
#10202 - Adapter for Ford GT500 Crankshafts

1/2"-20 to M12-1.5 X 3.5"
#10203 - Adapter for Ford Mod Motor Crankshafts

1/2"-20 to M12-1.5 X 1.5"

Specifications

CNC Machined Billet C1215 Alloy Steel Puller Plate
CNC Machined Billet 4140 Heat Treated Installer Studs
CNC Machined Billet 4140 Heat Treated and Nitrided Shaft.
CNC Machined Billet Alloy Nut
Precision Needle Roller Thrust Bearing Puller Plate
Black Oxide Finish on All Components
Many sizes of hardened puller bolts are included
Fits GM, Ford, Chrysler and many other crankshafts
Adapter Stud Kits are available for most imported engines
Durable Polyethylene Storage Box
NOTE: Will work as an installer for the Ford Mod Motor Dampers and LS Underdrive Dampers, but unfortunately the diameter of the bearing will not allow it to pull the damper from the engine. A generic puller that does not have the bearing will have to be used to remove those dampers.
